鋼板
販売
鋼板 寸法表
| 厚さ mm |
単位重量 kg/m² |
単位重量 kg/ft² |
3 × 6 914 × 1,829 |
4 × 8 1,219 × 2,438 |
5 × 10 1,524 × 3,048 |
5 × 20 1,524 × 6,096 |
|---|---|---|---|---|---|---|
| 1.0 1.6 2.3 |
7.850 12.56 18.06 |
0.7293 1.167 1.677 |
13.1 21.0 30.2 |
23.3 37.3 53.7 |
36.5 58.3 83.9 |
72.9 117 168 |
| 3.0 3.2 3.5 4 4.5 |
23.55 25.12 27.48 31.40 35.32 |
2.188 2.334 2.553 2.917 3.282 |
39.4 42.0 45.9 52.5 59.1 |
70.0 74.7 81.7 93.3 105 |
109 117 128 146 164 |
219 233 255 292 328 |
| 5 5.5 6 6.5 7 |
39.25 43.18 47.10 51.02 54.95 |
3.646 4.011 4.376 4.740 5.105 |
65.6 72.2 78.8 85.3 91.9 |
117 128 140 152 163 |
182 201 219 237 255 |
365 401 438 474 510 |
| 8 9 10 11 12 |
62.80 70.65 78.50 86.35 94.20 |
5.834 6.564 7.293 8.022 8.752 |
105 118 131 144 158 |
187 210 233 257 280 |
292 328 365 401 438 |
583 656 729 802 875 |
| 13 14 15 16 17 |
102.0 109.9 117.8 125.6 133.4 |
9.481 10.21 10.94 11.67 12.40 |
171 184 197 210 223 |
303 327 350 373 396 |
474 510 547 538 620 |
948 1,021 1,094 1,167 1,239 |
| 18 19 20 21 22 |
141.3 149.2 157.0 164.8 172.7 |
13.13 13.86 14.59 15.32 16.04 |
236 249 263 276 289 |
420 443 467 490 513 |
656 693 729 765 802 |
1,313 1,386 1,459 1,531 1,604 |
| 23 24 25 26 27 |
180.6 188.4 196.2 204.1 212.0 |
16.77 17.50 18.23 18.96 19.69 |
302 315 328 341 354 |
537 560 583 607 630 |
839 875 911 948 985 |
1,678 1,750 1,823 1,896 1,969 |
| 28 29 30 31 32 |
219.8 227.6 235.5 243.4 251.2 |
20.42 21.15 21.88 22.61 23.34 |
368 381 394 407 420 |
653 676 700 723 747 |
1,021 1,057 1,094 1,131 1,167 |
2,042 2,114 2,188 2,261 2,334 |
| 35 36 38 40 45 |
274,8 282.6 298.3 314.0 353.2 |
25.53 26.25 27.71 29.17 32.82 |
459 473 499 525 591 |
817 840 887 933 1,050 |
1,276 1,313 1,386 1,459 1,641 |
2,553 2,625 2,771 2,917 3,281 |
| 50 55 60 65 70 |
392.5 431.8 471.0 510.2 549.5 |
36.46 40.11 43.76 47.40 51.05 |
656 722 788 853 919 |
1,167 1,283 1,400 1,516 1,633 |
1.823 2,006 2,188 2,370 2,552 |
3,646 4,011 4,376 4,740 5,105 |
